AdBlue tankoló rendszer VAS 6960A ASE40464091023

AdBlue filling system VAS 6960A

Only for the USA market!

VAS 6960A is a mobile AdBlue filling system for passenger vehicles (of the Group), which drastically reduces the AdBlue filling time.
The device is also suitable for the more demanding refuelling requirements on the VW Sharan 2013 > and Audi A4 2013 >.
- Mains-independent operation by means of rechargeable battery.
- Automatic filling with AdBlue from commercially available 60/200 litre drums (genuine part number 200 litre drum: G 052 910 M9) or 1000 litre IBC (intermediate bulk container) with CDS vacuum connection.

- Automatic shut-off of filling nozzle with lowest volumetric flow (maximum fill level) to prevent displacement of air in AdBlue tank reserved as an anti-freeze measure
VAS 6960A features a multi-range mains unit and a 100 litre tank.
Versions ASE 404 640 70 086 to ASE 404 640 70 089 have been collated into ASE 404 640 71 000.

Technical data
Trolley made from galvanised and powder-coated steel for 100 litre canister, with 2 rollers and 2 castors, locking brake and nozzle holder, powder-coated surface.

Dimensions: approx. 96 × 58 × 108 cm (L x W x H)
Weight: approx. 48 kg (without AdBlue)

Suction connection: CDS adapter for connection to device's own 100 litre tank or commercially available containers.

Delivery pump: self-drawing, electric diaphragm pump with pressure switch, system delivery rate max. 6.5 l/min.
Power supply: leak-proof 12 VDC gel battery, 18Ah, electronic multi-range charger, charge level display.

Mains output: multi-range mains unit with 1.5 m long lead. Country-specific plug adapter.
Measuring mechanism with gauge (cannot be calibrated): digital gauge for amount delivered and total amount, battery charge status indicator and tank capacity.

Filling nozzle: quad sensor-controlled automatic filling nozzle FLACO ZV 10.2 A with foolproof adapter on AdBlue filler neck (compliant with ISO 22241-5) and status indicator as well as swivel joint.

Reservoir: 100 litre PE tank with CDS suction connection and opening for filler nozzle.
Dispenser hose: 2 m long with swivel joint.
Ambient temperatures: 0 to +30C°Mains voltage: 110 V 50/60 Hz to 240 V 50/60 Hz multi-range mains unit

Output: approx. 60 W
WEEE Group: 6 electrical and electronic tools
Type of battery: lead acid gel battery
Weight of battery (g): 5420
Number of batteries: 1

Items supplied
The production date of the devices is 2017.

- 1 × suction regulator (OEM kit) VAS 6960/1
- 1 × 200l hose fitting VAS 6960/2
- 1 × 60l hose fitting VAS 6960/3
- 1 × 100l tank
- 1 × operating instructions (various languages)
- 1 × adapter VAS 6960/5
- 1 × release tool VAS 6960A/6

#--- ASE 404 640 91 023 ---#

Dimensions of the package (l X w X h)
770 / 570 / 980
