Diagnosztikai rádiófej VAS 5054A ASE40525001001

The remote diagnosis head VAS 5054A enables wireless connection of diagnosis testers VAS 5051B, VAS 5052A, VAS 6150X and VAS 6160 to the diagnosis interface in the vehicle (provided the relevant permission for radio transfer is given and the equipment version supports this).
The USB cable included in the items supplied should be used for flashing.
Communication with the control units takes place in the remote diagnosis head. Only the commands/results are transmitted by radio. This ensures the highest level of data security.
The remote diagnosis head is best suited for road tests or exhaust emissions testing, for example.
The remote diagnosis head VAS 5054A is also suitable for ""Pass Thru"" applications (EU5).
Design and features
Remote diagnosis head dimensions: 114 x 48 x 25 mm
Weight: 645 g complete with storage case, approx. 100 g for remote diagnosis head alone
Voltage supply: 8 to 18 V, via onboard electrical supply
Current draw: approx. 200 mA with 12V
Device interface: Bluetooth V1.2 class 2, 10 m range, USB V2.0 full speed, 12 Mbit/s, mini USB socket type B
Vehicle interface: Diagnosis connector compliant with ISO 15031-1 and SAE J1962
CAN: 1 channel CAN 2.0B with CAN high speed bus compliant with ISO 11898-2 and CAN low speed compliant with ISO 11898-3
ISO 9141-2: K and L-lead for 12 V vehicle systems
SAE J1850: SAE J1850 PWM and VPW
Digital inputs: Ignition (terminal 15)
Power saving mode: Automatic deactivation after set period, switched on with ignition
Temperature range: Operation 0 to +50ºC, storage -25 to +85ºC
Identifying colour
RAL 7021, black grey
Items supplied
Remote diagnosis head VAS 5054A, 3m USB cable (ASE 405 251 00 001) with tough workshop USB connector to tester side VAS 5054A/1
CD with handbook and installation software for Pass Thru application

24 months for USB cable, 36 months for remote diagnosis head
------------------------------
ASE 405 250 01 001
------------------------------

Dimensions of the package (l X w X h)
274 / 174 / 125
