ASE44115900000 Test adapter VAS 6606/29

Test adapter VAS 6606/29

The test adapter VAS 6606/29 is used for diagnosis on the battery module and the battery modules control unit (CMC). It was first used in the AUDI e-tron 2019. The application is described in the relevant workshop manual. The test adapter VAS 6606/29 is comprised of two adapter cables with the following connections:

Cable 1:
Isolator box VAS 6606 port A
Battery module connector (connector A)
CMC connector (connector B)

Cable 2:
Isolator box VAS 6606 port B
Battery module socket (socket A)
CMC socket (socket B)

The scope of supply also includes a film for placing on the test box. The film numbers the pins of electrical connectors A (A1 to A12) and B (B1 to B10) and contains a colour marking which can also be found on the cable.
The test adapter VAS 6606/29 is used in combination with the isolator box 6606.
Detailed information on its use can be found in the Workshop manual or the “Guided Fault Finding”.

Material: PA66-GF30, PBT-GF10, XPE, PA4T-GF30, PA, PET, PP, PE plastic), CuSn4 (bronze), CuNiSi (copper alloy), CuZn30 (brass), X10CrNi18-8 (stainless steel), Cu-ETP (electrolytic copper)
Packaging: Blown film

Warranty: 36 months

Technical data:
- Dimensions (LxWxH) [mm]: 2300 x 200 x 100
- Weight: 1.4 kg gross
- Weight: 1.2 kg net

Identification colour
- Connector: Black
- Cable: Orange

Delivery includes
- VAS 6606/29 – test adapter, comprising:
- 2 adapter cables, 1 template (film), operating instructions

Recommended accessories
- VAS 6606

#--- ASE 441 159 00 000 ---#

Dimensions of the package (l X w X h)
500 / 320 / 80
