Forgócsavar VAS 691 015 ASE69101500000

Swivel bolt, M10 VAS 691 015
Use: For lifting and lowering the top part of the housing on the high-voltage battery in the Audi e-tron 2019>. Required solely for battery repair.
Instructions on how to use it are given in the Workshop Manual.
Features:
Ball bearing for low-friction 360° rotation (including under load)
Screw is protected against corrosion and 100% crack-tested
First use: Audi e-tron 2019>
In combination with the VAS 6100 workshop hoist and the T40155 retaining strap

Technical data
- In accordance with DIN EN 1677
- In accordance with the EU Machinery Directive 2006/42/EC
- In accordance with the DGUV (German Social Accident Insurance)
- Permissible loading capacity (lateral): 500 kg
- Permissible loading capacity (axial): 1200 kg
- Can be rotated 360°
- Thread: M10
- Thread length: 35 mm
- Screw 100% crack-tested
- Material: Steel
- Surface: Powder-coated, electrogalvanised (Colour: Orange RAL2004)

Delivery includes
1 unit incl. operating instructions

Dimensions of the package (l X w X h)
210 / 160 / 50
